AND RTG-1210 Universal Material Testing Machine

SKU
RTG-1210
Out of stock

Highly accurate Class 1 testing machine
Available range 1 kN
High-speed sampling 1 msec
A maximum of 13 Input signal channels
Various operational environments

AND RTG-1210 Universal Material Testing Machine

AND TENSILON RTG-1210  Universal Material Testing Machine was developed using out superior knowledge of force sensor and measurement control technology, enables connection between sensor and machines. Our measurement control system at the core of our testing machines offer the highest accuracy and most rapid calculation in the world.

TENSILON RTG-1210 is our newest universal testing machine providing cost-effective measurement with a higher level of accuracy.

Loading system Closed-loop microcomputer controlled digital servomechanism
Maximum capacity 1 kN
Effective test width 420 mm
Crosshead stroke 1100 mm
Effective stroke 775 mm
Crosshead speed 0.05 to 1000 mm/min
Crosshead speed accuracy ±0.2%
Crosshead random speed 0.01 mm/min step in crosshead speed range
Crosshead speed and load capacity Maximum load capacity in full speed range
Crosshead return speed 1000 mm/min or 500 mm/min
Load measurement accuracy ±1% of reading (within range of 1/1 to 1/500 of load cell rating)
Load range Fully automatic range swithcing (up to 128 folds)
Load calibration One touch operation load calibration with the calibration circuit embedded in the load cell. Equipped with a load cell rating discrimination function
Sampling speed 1 msec
Safety function for overload Provided
Stroke limiter Upper - Lower limit 2 points
Power requirement AC 100V, 50/60 Hz
Dimension / Weight 708 x 436 x 1555 mm / 100kg
SKURTG-1210
Weight100.000000
Dimension708 x 436 x 1555mm
ManufacturerAND
Data loggerNo
Resolution No
Measurement RangeMaximum capacity : 1 kN
Effective stroke : 775 mm
Other FunctionNo
Power SupplyAC 100V
Water resistanceNo
Sensor Output InterfaceNo
Accuracy±
