Mitutoyo M-331-252-30 Spline Micrometer (25 - 50mm)

SKU
M-331-252-30
main product photo
Out of stock

Spline Micrometer
Measuring Range: 25 - 50mm
Constant force: Ratchet Stop
IP65 water / dust protection
Measuring faces: Carbide
Mitutoyo, Japan

Category: Mitutoyo
Mitutoyo

Mitutoyo M-331-252-30 Spline Micrometer Series

Measuring Range: 25 - 50mm
Resolution: 0.001mm
Accuracy ±2µm
Type A (ø3mm)
Flatness: 0.3μm
Parallelism: (2 + maximum range (mm) / 100)μm
Constant force: Ratchet Stop
IP65 water / dust protection
Measuring faces: Carbide
Battery SR44  ×1
Mitutoyo, Japan

Feature Mitutoyo M-331 Spline Micrometer Series

Feature Type A Type B
M-331 M-331 M-331



Dimention Mitutoyo M-331 Spline Micrometer Series

Dimention Models up to 75mm measuring range Dimention Models over 75mm measuring range
M-331 Dimension M-331 Dimension
Range (L) a b c
0 7.3 32.5 17.5
25 10.1 47
50 11.5 60
75 16.7 76 20.3



Specification Mitutoyo M-331 Spline Micrometer Series

Model Range Resolution Accuracy Remarks
Metric
331-251-30 0 - 25mm 0.001mm ±2µm Type A
331-252-30 25 - 50mm
331-253-30 50 - 75mm
331-254-30 75 - 100mm ±3µm
331-261-30 0 - 25mm ±2µm Type B
331-262-30 25 - 50mm
331-263-30 50 - 75mm
331-264-30 75 - 100mm ±3µm
Inch/Metric
331-351-30 0 - 1" .00005" / 0.001mm ±.0001" Type A
331-352-30 1" - 2"
331-353-30 2" - 3"
331-354-30 3" - 4" ±.00015"
331-361-30 0 - 1" ±.0001" Type B
331-362-30 1" - 2"
331-363-30 2" - 3"
331-364-30 3" - 4" ±.00015"
SKUM-331-252-30
Weight0.000000
Dimension0
ManufacturerMitutoyo
Data loggerNo
Resolution 0.001mm
Measurement Range25 - 50mm
Other FunctionNo
Power SupplySR44
Water resistanceIP65
Sensor Output InterfaceNo
Accuracy±2µm
