Mitutoyo M-102-302 Outside Micrometer (25 - 50mm)

SKU
M-102-302
main product photo
Out of stock

Outside Micrometer
Range Measuring 25 - 50mm
Heat-insulated frame
Constant force Ratchet stop
Measuring faces: Carbide
Mitutoyo, Japan

Category: Mitutoyo
Mitutoyo

Mitutoyo M-102-302 Outside Micrometer

Range Measuring 25 - 50mm
Graduation 0.01mm
Accuracy ±2μm
Flatness 0.6µm
Parallelism 2µm
Mitutoyo, Japan


Features Mitutoyo M-102 Outside Micrometer Series

M_102 M_102 M_102


Constant-force device Mitutoyo M-102 Outside Micrometer Series

Ratchet stop type Ratchet thimble type

M_102

M_102



Dimention Mitutoyo M-102 Outside Micrometer Series

Dimention Range a b c d

M_102

 0 - 25mm 5 26 2.8


 30.3
25 - 50mm 8 32 55.3
50 - 75mm 10 45 80.3
75 - 100mm 11 58 105.3

Note: The shape of the thimble changes on the model with ratchet thimble.



Specification Mitutoyo M-102 Outside Micrometer Series

Model Range Graduation Accuracy Flatness Parallelism Constant-force device
M-102-301 0 - 25mm 0.01mm ±2µm 0.6µm 2µm Rachet stop
M-102-311 0.001mm ±1µm 0.3µm 1µm
M-102-313 Friction thimble
M-102-302 25 - 50mm 0.01mm ±2µm 0.6µm 2µm Rachet stop
M-102-312 0.001mm ±1µm 0.3µm 1µm
M-102-303 50 - 75mm 0.01mm  ±2µm 0.6µm 2µm
M-102-304 75 - 100mm ±3µm 3µm
SKUM-102-302
Weight0.000000
Dimension0
ManufacturerMitutoyo
Data loggerNo
Resolution

Graduation - 0.01mm

Measurement Range25 - 50mm
Other FunctionNo
Power SupplyNo Need
Water resistanceNo
Sensor Output InterfaceNo
Accuracy±2µm
