Mitutoyo M-406-353-30 Outside Micrometers (3" - 4")

SKU
M-406-353-30
Out of stock

Outside Micrometers
Non-rotating spindle.
Equipped with Ratchet Stop for constant measuring force.
Mitutoyo, Japan

Mitutoyo M-406-353-30 Outside Micrometers

Measuring Range: 3" - 4"
Resolution: .00005" / 0.001mm
Accuracy: ±.0002"
Flatness: .000012"
Parallelism: .00016"

Outside Micrometers
Non-rotating spindle.
Equipped with Ratchet Stop for constant measuring force.
Battery SR44 ×1
Battery Life: approx 2.4 ปี
Mitutoyo, Japan

Dimension Mitutoyo M-406 Outside Micrometers Series

M-406 Dimension M-406 Dimension
Range L a b c
0 - 25mm 0 7 32 2.8
25 - 50mm 25 9.8 47
50 - 75mm 50 11.2 60
75 - 100mm 75 14.6 57 2.3

Specification Mitutoyo M-406 Outside Micrometers Series

Metric
Models Range Resolution Accuracy Flatness Parallelism
406-250-30 0 - 25mm 0.001mm ±3μm 0.3μm 3μm
406-251-30 25 - 50mm
406-252-30 50 - 75mm
406-253-30 75 - 100mm ±4μm 4μm
Inch
Models Range Resolution Accuracy Flatness Parallelism
406-350-30 0 - 1" .00005" /
0.001mm
±.00015" .000012" .00012"
406-351-30 1" - 2"
406-352-30 2" - 3"
406-353-30 3" - 4" ±.0002" .00016"
SKUM-406-353-30
Weight0.000000
Dimension0
ManufacturerMitutoyo
Data loggerNo
Resolution .00005" / 0.001mm
Measurement Range3" - 4"
Other FunctionNo
Power SupplySR44 x 1
Water resistanceNo
Sensor Output InterfaceNo
Accuracy±.00015"
