Hioki-CM7290 หน้าจอแสดงผล สำหรับ Current Sensors CT7000 Series

Hioki-CM7290 หน้าจอแสดงผล สำหรับ CT7000 Series AC/DC Current Sensors

Measurement parameters : DC, AC, DC+AC, Hz
Output method : WAVE, RMS, PEAK, FREQ
ใช้งานร่วมกับ AC/DC Auto-zero Current Sensor (แยกจำหน่าย)

รองรับ AC adapter และ Alkaline batteries AA x 2
ขนาดตัวเครื่อง 52 x 163 x 37mm (220g)
ยี่ห้อ HIOKI, Japan

Specifications

Sensor (แยกจำหน่าย)
Model	HIOKI-CT7642	HIOKI-CT7742	HIOKI-CT7636	HIOKI-CT7736	HIOKI-CT7631	HIOKI-CT7731
Measurement parameters	DC, AC, DC+AC, Hz
Crest factor	3 at 5000 count or 2.5 at 6000 count for AC and DC+AC
Output method	WAVE, RMS, PEAK, FREQ
Input connectors	HIOKI PL 14
Output update time	PEAK--- FAST: 0.02 s / NORMAL: 0.2 s / SLOW: 1 s FREQ--- FAST: FAST: 0.2 s / NORMAL: 0.2 s / SLOW: 3.0 s (WAVE, RMS: analog output)
PEAK sensing duration	2 ms or greater (during PEAK MAX/PEAK MIN and PEAK output)
Other functions	Auto range Zero adjustment at power-up Analysis display Filter Output amplification Display value hold Backlight Auto-power save Save settings keypad lock
Typical accuracy (WAVE output DC)	±2.0% rdg. ±10.8 mV (60.00 A range)		±2.5% rdg. ±30.8 mV (60.00 A range)		±1.5% rdg. ±5.8 mV (60.00 A range)
Typical accuracy (RMS output AC)	±2.3% rdg. ±10.8 mV (60.00 A range)		±28% rdg. ±30.8 mV (60.00 A range)		±1.8% rdg. ±5.8 mV (60.00 A range)
Communication interface	Built in Bluetooth® 4.0 LE, Display of measured values on an iOS or Android handset using Bluetooth® communications (CM7291 only)
Power supply	LR6 alkaline batteries (AA) ×2, Continuous use: 16 h (backlight OFF and WAVE or RMS output, when used with CT7600s), Rated power 2.5 VA or AC adapter 9445-02/03 (100 to 240V AC), or 5 to 15 V DC external power supply, Rated power 2.5 VA
Dimensions / Weight	52 x 163 x 37mm (220g)
Accessories	LR6 alkaline batteries ×2 Protector ×1 Instruction manual ×1
